This guide will show you how to connect your Verifone EFTPOS terminal to Bustle, so payment can be sent straight from the till to the terminal for processing.
Ensure your Terminal works with Bustle:
What Verifone Terminals can be setup with Bustle?
What Verifone Terminals can be setup with Bustle?
âBustle can connect to both VX-Link and VCloud terminals
Paymark/Worldline Network
VX820 Duet
VX520-C 1 and 2 Piece
VX680 WiFi
V240m
V200t
V205c
V400c
V210
M400 (can integrate but does not have a printer)
P400 (can integrate but does not have a printer)
Verifone Network
VX820 Duet
VX520-C 1 Piece
VX690
T650p
T650c (coming soon)
The list below are also compatible but do not have printers (chat further with us or Verifone if you have one of these)
P630
M424
M440
Ux700
Contact Eftpos NZ (NZ Eftpos) 0800 EFTPOS or your nearest Verifone partner for more information. Alternatively call 0800 Verifone.
â
Before you begin, youâll need:
One Verifone EFTPOS terminal for each Bustle till (iPad)
Your Bustle tills (iPads)
Your EFTPOS terminal and iPad connected to the same Wi-Fi network
Access to Bustle Hub (hub.heybustle.com)
Note: You will need to contact your Verifone provider in this process.
Note: Verifone Errors
We can help with connecting your EFTPOS terminal to Bustle and checking your Bustle settings. However, if you see an error while setting up or using the terminal - including an EFTPOS error shown in Bustle - you'll need to contact your EFTPOS provider. They manage the terminal and are best placed to troubleshoot the error.
1. From the Bustle Hub (hub.heybustle.com) select your integration type
In the Hub, head to Setup > iPad Setup
Use the Eftpos Integration selector to select your provider - Either Verifone VX-Link or Verifone VCloud (If unsure, reach out to your provider).
VX-Link
V Cloud
Head back to the iPad - In the Bustle iPad till app go to: Settings > Sync Menu.
After syncing is finished, fully close and restart the Bustle iPad till app. You'll see an "EFTPOS" option appear in your iPad settings.
â
2. Get your Verifone terminal ready for Bustle
Before connecting your terminal in Bustle, call your EFTPOS provider and let them know you want to connect your Verifone terminal to Bustle - mentioning that it is an iPad till system.
Set the terminal up to connect to an iPad till over your local network.
Set the terminal to a Static IP address in Vericentre (this is the verifone setup tool).
Tell you how to find your terminal's IP address or serial number - you'll need this when setting it up in Bustle.
If your provider needs further technical details, read this out:
The terminal needs to be set up with an IP interface listening on port 20001. This is done by creating a record in Vericentre, the TMS (Terminal Management System) and downloading it to the terminal.
3. In the till connect your Verifone terminal to Bustle
On your Bustle iPad till, go to Settings > EFTPOS > Connect.
Next, enter the details for your terminal
Replace any existing text in the field with your terminal's IP address or Serial Number.
VX-Link: Enter the terminal's IP address.
VCloud: Enter the Serial Number (S/N) shown on the back of the terminal.
Press Continue. If everything is connected correctly, you'll see a success message.
Give it a quick test
Press the Settings button in the top-right corner, then select Logon under the Verifone Admin Functions.
Your terminal will run a quick check and print a message confirming whether it was successful.
Troubleshooting Steps
Ensure âAllow Network Permissionsâ is enabled on your iPad.
Make sure youâve selected the correct integration type in the hub.
Have you entered the correct IP address / Serial Number?
Receiving an error message? Follow these steps:
Frequently Asked Questions
How do I set up Tipping & Surcharge?
How do I set up Tipping & Surcharge?
Verifone terminals have integrated tipping and surcharge - This is where any tip or surcharge totals from the terminal are recorded in your cash up. This should be switched on by default (contact Verifone if not) and you'll need to be on Bustle Till iPad app version 5.0 or greater.
Will I need to make changes to my router or network?
Will I need to make changes to my router or network?
Please Note: We highly recommend having a dedicated network and a router with a strong signal, solely for Bustle and Verifone devices. Other devices (from phones to streaming cameras) joining your network can cause communication issues.
